Features:

• roll diameter: 80 mm

• extreme exquisite lightweight structure design is easy to carry

• easy paper structure is easy to use and maintenance

• equipped with large capacity rechargeable lithium battery 7.4V, 1500 Ma

• 1.2 meters cement ground height of fall

Multiple wired and wireless interfaces optional

• support the client local program upgrade

• equipped with Windows computer end drive

• equipped with WM, WINCE, Symbian, presentation software and dynamic link library Android platform

• Bluetooth host function

Applications:

• copy watch - electrical water meter charge

• Insurance - insurance field fast loss

• warehousing, inventory / distribution / warehousing

• parking - confirm parking time charge of Statistics

• logistics, express transportation invoices / goods delivery order

• mobile sales - ticket / fast consumer goods such as mobile sales

• police and police / management / business field Enforcement / health supervision

Parts list

• • • • leather belt buckle battery serial line USB interface line • rolls • charger

Detail specification

Print line thermal

The printing speed of 60 mm / s.

Effective print width 58 mm

The density of 8 / mm, 384 point / line

Printing character ANK: 8 x 16, 12 x 24 GBK:16 x 16, 24 x 24

Characters per line ANK: 48, 32 GBK:24, 16

The paper type thermal label paper

Paper width of 30 ~ 60 mm

Paper roll diameter: 40 mm

Roll core diameter of 15 mm (minimum)

Paper thickness 0.12 mm

The paper simple paper

The life of the printhead 50 kilometers

Bar code 1-D:UPC-A, UPC-E, EAN-13, EAN-8, CODE39, ITF25, CODABAR, CODE93, CODE128

2-D:QR Code

ESC/POS instruction set

Interface RS-232 port, USB, Bluetooth, infrared

Power supply AC00-250V/1.0A

DC7.4V battery, rechargeable lithium battery 1.5A

The weight of 197 grams (not including rolls, including the battery)

Dimensions (WxLxH) 99 x 136.6 x 51 mm

Working temperature -10 ~ 50 ° C

Storage temperature -20 ~ 70 ° C

Work humidity 20 ~ 85%

Storage humidity 5 ~ 95%
